7.5MW Shinko Steam Turbine Generator Set 60Hz. Never used.!

7.5MW Shinko Steam Turbine Generator Set for Sale. 60Hz. 6,600 Volts. YOM 2009. Never used. Excellent condition. Steam conditions: 31kg/CM2.A, 385Cº, 42,500 kg/hr. Shinko Generator, 7,500/1,800 rpm.

1. Synchronous Brushless A.C. Generator

ITEM	SPEC.	ITEM	SPEC.
Maker	Shinko-Japan	EXC. Volt	95V
Type	FK7G-AF-1250	FLD. Current	450A
Output	9375KVA	INSU. Class ARM	F
Volt	6600KVA	“ FLD	F
Current	820A	DEG. of protection	IP44
P.F	0.8	Cooling	IC81W
Phase	3	Coolant temp.	40℃
Pole	4
Frequency	60Hz
Speed	1800min^-1
Rating	CONT

Exciting equipment		EXC. System Brushless exc.
Output	48KW	Exc. Volt	50V
Voltage	95V	Fld. Current	6A
Current	50.5A
Standard	JEC-2130	Mfg. date	SEP. 2008
Net weight(Total)	25,300kg(27,000)

2. Gear Driver

ITEM	SPEC.
Maker	SEISA Gear - Japan
Model	NDM4248T
Nominal Power Rating	7500KW
Input speed	7477rpm
Output speed	1800rpm
Ratio	1/4.154
Mfg. date	JUL.2008
Working No.	07KADA50
Net weight(Total)	5,300kg(6,040)

3. Turbine

ITEM	SPEC.	ITEM	SPEC.
Maker	Shin Nihon machinery
Type	C5-R8-ER
Output	7500kw
Speed	7477/1800rpm
Inlet steam press	31kg/cm².A
Inlet temp.	385deg C
Max. extraction press	9.0+.-0.25kg/cm²
Control extraction	At turbine nozzle
Max. inlet steam flow	42500kg/hr.
Max. steam extraction	0&3000 to 25184kg/hr.
Max. steam exhaust
Net weight(Total)	20,000kg(23.350)

Item List

Item	Case no.	Net weight(kg)	remark
Steam Turbine	1	20,000	Special tools, spear part
Gear Driver	2	5,300
Lagging cover	3	450
Turbine control panel	4	1,100
Oil unit	5	3,000
Oil cooler	6	1,200
C.O.P Unit	7	500
Gland condenser & etc.	8	6,000

Item	Case no.	Net weight(kg)	remark
Generator	1	25,300	Main terminal box, liner, anchor bolt. Sheet plate ,etc.
Air cooler & top cover	2	2,000
Generator CB panel, LA/SA panel	3	1,800
NGR panel	4	1000
Generator control panel	5	600
Circuit breaker	6	50
Spear part	7	50	Fuse, lamp bulb, etc.
